Alumina Ceramic Tile
Description
Technical Parameters
Product Introduction
The products, which are of excellent wear-resistance, impact-resistance, easy operation are ideal surface wear-resisting material for material transfer equipment in mining, iron & steel works, thermal & power plants, mine, etc, and can extend operating life of equipment effectively. Theoretically the life time of the alumina ceramic is about 260 times longer than that of manganese steel and 170 times longer than that of chrome steel.
Product Size
| Size | Length(mm) | Width(mm) | Thickness(mm) | Shape |
| 10x10 | 10 | 10 | 1.5-10 | Mosaic/hexagonal |
| 11.55x11.55 | 11.55 | 11.55 | 3-12 | Mosaic/hexagonal |
| 12x12 | 12 | 12 | 3-12.7 | Mosaic/hexagonal |
| 17.5x17.5 | 17.5 | 17.5 | 4-10 | Mosaic/hexagonal |
| 20x20 | 20 | 20 | 5-15 | Mosaic/hexagonal |
| 25x25 | 25 | 25 | 5-15 | Mosaic/hexagonal |
| 50x25 | 50 | 25 | 5-10 | Plain Tile without hole |
| 50x50 | 50 | 50 | 5-15 | Plain Tile without hole |
| 100x100 | 100 | 100 | 6-15 | Plain Tile with or without hole |
| 150x100 | 150 | 100 | 6-100 | Plain Tile with or without hole |
| Remark: More than 2000 sizes and shapes are available up to customer requests |
Key benefits:
·Excellent anti-wear and corrosion resistance.
·Longer life than that of traditional wear protection material.
·Avoid shutdown time and maximize the productivity of your plant.
Application
| Applications & Hardware | ||
| Application | Fastening Methods | Backing plates |
| raw meterial feed | rubber bond | plain rubber with captive studs |
| head chute liner | studs | mild steel |
| impact curtains | captive socket | 3 Cr 12 |
| chute liner | plug weld | Stainless steel |
| rock boxes | ||
| skirt boards | ||
| bucket liner | ||
RFQ
1.What's the alumina content of ceramic tile?
We have 92% and 95% alumina ceramic tile now.
2.What's the Mosh hardness of ceramic tile?
More than 9
3. Would you pls introduce application of alumina ceramic tiles?
Widely used in cement plant, chemical, rubber and so on, is the ideal surface wear-resisting material for material transfer equipment in mining, iron, thermal & powder plants, etc. The life time of the alumina ceramic is about 260 times longer than that of manganese steel and 170 times longer than that of chromel steel.
4. Can you manufacture ceramic tile base on drawings?
Yes, we can. We can design and manufacture base on requirement of customers.
5.What's the standard dimension?
150x100x(6-50)mm series, 150x60/(57-58)x(12.7-14)mm series
125x75x6-50mm series 120x80x(6-30)mm series
70x70x20/25mm hole series 150x50x(6-25) series
Arc tile, pipe tile, corner tile, interlocking tile, etc
6.What's the package of tile?
Carton box on the pallet
